Self storage and commercial door systems

 Choosing a vendor for your self storage door needs is a big decision! You want a company that has both experience and innovation, and that’s where Storage Solutions comes in.  We offer a full line of roll-up and swing storage unit doors in varying sizes for all types of self-storage facilities.

• Pre-Lubricated Springs During production, springs are factory lubricated and enclosed  in a tube to protect them from the environmental elements.
• Dead Axle & Barrel Assembly An enclosed spiral barrel houses the dead axle assembly  and offers durability and smoother operation as weight  is distributed throughout the barrel.
• Ratchet Tensioning Device Allows you to simultaneously fine tune springs due to the eight different positions on the tension wheel, which provides equal pull on the left and right sides to ensure balanced operation  of the door.
• 26-Gauge Corrugated Door Curtain Manufactured from galvanized grade 80 steel and coated with super durable polyester paint in more than 30 color options.
• Insulated Version Available Side and top draft stops included.

650 Series Features Include

Door Springs

• Coated with grease during production, which prevents rust and corrosion
• Enclosed in a tube for lifetime protection
• Provide for smooth door operation

Ratchet Tensioning Device

• Allows for simplified spring tensioning
• Tensions all springs at once
• Requires no pins to hold the tension on the spring

Radial Ball Bearings

• Provided at no additional cost
• Permanently lubricated
• Require virtually no maintenance

Dead Axle and Torque Tube Assembly

• Tube housing protects springs and strengthens the axle
• Eliminates axle push and shift that a live axle would create
• Allows for springs to be tuned all at the same time

 750 Series Features Include

• Minimizes the locking and reinforcement needed to strengthen the door to pass rigorous wind load testing.
• Fewer friction points and less additional weight results in a door that operates better and still yields greater strength than any other available to the self storage industry.
• Meets the requirements of ASCE 7 (American Society of Civil Engineers). The ASCE Standard is used in the Florida Building Code and the International Building Code.
• Applicable opening sizes range from 3′ wide through 10′ wide, with the maximum height being 10′.
• Locking device may be located on the curtain or the bottom bar.
• Doors may be installed on steel, concrete, or filled block jambs.
• Higher wind load ratings are available for certain sizes and can be determined on an individual basis.

 850 Series Features Include

• Pre-Lubricated Springs During production, springs are factory-lubricated and enclosed in a tube to protect them from the environmental elements.
• Dead Axle & Barrel Assembly An enclosed spiral barrel houses the dead axle assembly and offers durability and smoother operation as weight is distributed throughout the barrel.
• Ratchet Tensioning Device Allows you to simultaneously fine-tune springs due to the eight different positions on the tension wheel, which provides equal pull on the left and right sides to ensure balanced operation of the door.
• 24-gauge Corrugated Door Curtain Manufactured from galvanized grade 80 steel and coated with super durable polyester paint, available in white only.
• Metal Windlocks 11-gauge provides strength and security. Windlocks do not come in contact with guides during normal door operation.
• Insulated version is available. Side and top draft stops are included.

Choosing a vendor for your rolling steel door needs is a big decision! You want a company that has experience, innovation and dedication to customer care – that's where Storage Solutions comes in! We offer every product series, model size and option in the book! With a full-line of rolling steel doors to fit virtually any application, from warehouses and loading docks to freight terminals and distribution centers, each model encompasses structural integrity and is built to last.  In addition to our wide selection of models and product offerings, our rolling steel doors are known for minimal maintenance and easy installation.  The available options include: Commercial Slat Doors, Heavy Duty Service Doors, Fire Doors, Fire Rated Counter Shutters, Insulated Service Doors, Counter Shutters and Grilles.

300 Series Commercial Slat Door

300 SERIES COMMERCIAL ROLLING SLAT DOOR is produced with the highest quality and durability in the industry. The 300 Series consists of 3” – 24 or 22-gauge slats with a flat or curved profile. The slats are commercial grade galvanized steel and coated with Super Durable polyester paint. Model 324, 24-gauge, is available in sizes up to 16’ wide x 16’ high. Model 322, 22-gauge, is available in sizes up to 12’ wide x 12’ high, both models are a perfect choice for freight terminals, commercial and industrial applications.

• Roll-formed 12-gauge galvanized guides
• Nylon endlocks
• Dual galvanized steel slide bolt locks
• Chain hoist operation
• Drum assembly with pre-installed curtain

Options

Steel Mounting Plates: For lateral jamb extension to provide door support.

Top Draft Stop: To seal tight at the header to reduce air infiltration.

Guide Weather Seal: To seal tight at the jambs to reduce air infiltration.

Vision Lites: 5” x 3/4” cut out spaced approximately 3” apart and covered with clear Lexan (flat slat only).

Structural Steel Upgrade Guide: 3-piece structural steel guides. .

Windload: Available design to +40/-37 for 14’ wide (test) Model 324 (24-gauge). Windload varies by model.

Powder Coating: Available on all gauges flat or curved profile. Consult factory for available colors.

400 Series Heavy Duty Service Door

The 400 Series Rolling Service Door delivers strength, versatility, and lasting performance. Available with 3” slats in multiple gauges  and profiles, it fits openings up to 40’ wide or 30’ high and offers Windload  and Miami-Dade options for high-wind areas—making it ideal for industrial  and commercial use

Options

Finishes: white topcoat, gray topcoat, tan topcoat, galvanized, stainless steel, aluminum, and custom powder coat.

Durable construction: engineered for strength and long-term performance

3” slats: available in 24-, 22-, 20-, or 18-gauge steel; flat, curved,  or perforated

Vision panels: 5” x 3/4” cut out, 3” apart, covered with clear Lexan  (Flat Slat Only)

Wide size range: up to 40’ wide × 30’ high; varies by model

Certified options: Windload and Miami-Dade approved for high-wind regions

Versatile use: ideal for industrial and commercial applications

500 Series Rolling Fire Door

The 500 Series Rolling Fire Door is built for openings requiring a fire-rated solution. Available with 3” flat slats in 22-, 20-, or 18-gauge steel, it installs to steel, concrete, or masonry and sizes up to 30’ wide x 24’  high (max 600 sq. ft.). Featuring a space-saving design and smooth operation,  its fail-safe system activates via fusible links, smoke detectors, or connection  to a central alarm.

• U.L. Label sizes up to 120 sq. ft., oversized labels are provided for openings up to 600 sq. ft. All doors comply with 45 minute, 1-1/2 hour, 3 hour, and 4 hour (18-gauge only)
• Slats: 22, 20, and 18-gauge galvanized steel flat slats, galvanized according to ASTM A-653 and finished with a high-tech polymer based super durable polyester topcoat.
• Guide assembly, barrel assembly, and hood
• Floor level release and reset handle provided with the chain hoist, key test station provided with motor operation. No tools or ladders are required for drop test or reset our simple test fire door
• Malleable cast iron endlocks  on alternating slats
• Two-piece steel bottom  bar with seal
• Chain hoist with fusible link  and 30’ cable
• 1/4” steel head plates
• Torsion springs rated  25,000 cycles
• Auto-reset drop test
• Guides, bottom bars, and headplates are powder coated black at  the factory

600 Series Insulted Rolling Service Door

The 600 Series Insulated Rolling Service Door delivers durability, thermal efficiency, and high performance. Its 24–18 gauge slats with  a 24-gauge back encase a 5/8-inch polyurethane core (R-value 7.2). Sizes range from 40’ x 16’ to 28’ x 26’ with optional Windload and Miami-Dade certifications, making it ideal for industrial, commercial, and climate-controlled applications

Standard Features Include

• Enclosed hood

• Reduction gear chain hoist

• 3-piece structural  steel guides

• Double angle bottom bar  with weather seal

• 2-year limited warranty

• Guides, bottom bars, and headplates are powder coated black at  the factory

Options

Electric Operation: Motorized operation at the push of a button  (bracket available on request) Miami-Dade Certified: Impact rated 80 ft/sec & +60/-65 PSF

Slide Bolt Locks: Dual steel locks for padlocks (standard on manual/ push-up doors)

Vision Panels: 5” x 3/4” cutouts spaced ~3” apart with clear Lexan

Windload: Optional up to ±50 PSF (varies by size/model)

High Cycle Springs: Available in 50,000 or 100,000 cycles

700 Series Counter Shutter Door

Janus 700 series counter Shutter Door is designed for finished applications providing security and beauty blended with smooth, quiet, and effortless operation. The 700 Series is available in clear anodized aluminum, 22-gauge painted steel, or stainless steel. The 700 Series Counter Shutter offers a compact design requiring minimal headroom and is the perfect choice for pharmacies, cafeterias, concession areas, ticket counters, nurse/hospital desks,  and many more applications.

Standard Features

• Steel end-locks

• Enclosed hood

• Slide bolt locks

• Flat slats with 1- 1/2” high profile

•  Aluminum angle bottom bar  with weather seal

• 2-Year Limited Warranty

• Manual push up to 10’- 4” wide

•  Five finishing options: white, gray, tan topcoats, and clear anodized aluminum, galvanized and stainless steel

Options

Mounting: Face of wall, between jamb above lintel or between jamb under lintel.

Sizes: Up to 14’- 4” wide X 10’- 4” high.

Operation: Manual push up or crank with handle.

Locking: Slide bolt locks, thumb turn lock or cylinder locks.

Powder Coating: Available on all gauges flat or curved profile. Consult Storage Solutions for available colors.

800 Series Rolling Grille Door

The 800 Series Rolling Grilles are designed to provide a high level of security while allowing for maximum visibility. With smooth operation and a variety of designs, the 800 Series Rolling Grille doors are a proven solution for a wide variety of environments including: parking garages, hospitals, pharmacies, schools and universities, retail outlets, and restaurants.

Standard Features

• Built-in charge arm allows quick safe adjustment to achieve the perfect charge

• Extruded aluminum bottom  bar and guides

• Drop-in style end plates  for quick installation

Options

Mounting: Face of wall or between jambs.

Locking: Slide locks (interior & exterior), cylinder locks,  or thumb turn.

Operation: Manual, crank, hoist, and electric operator.

Finishes: Clear Anodized, Black Anodized, Bronze Anodized,  Light Bronze, Anodized, and Champagne Anodized.

Five Finish Options

• Straight Grille Pattern

• Brick Grille Pattern

• Perforated Aluminum

• Solid Aluminum

• Polycarbonate Panels
